Crane components
Equipment:
- Radio Remote Control
- Conductor
- Gearbox
- Hook
- Wire Rope
- Other types
Radio Remote Control
Independent LEDs, indicate the status of the battery
Activation of the transmitter is protected by an electronic key-code and an auto shut-off option which is programmable
The system automatically change to another frequency in the presence of radio interference
Eco power management system. Save on batteries
It can receive and display via 4 LEDs signals coming from the receiver (relay action feedback)
Mushrooms type EMO button
Internal BootLoader, up firmware to the date by using computer
Wireless pairing procedure using the keyboard pushbuttons
?QI wireless charging pad is optional in New 2016 K plus series
Conductor
Cariboni centre of excellence based in Lecco has 110 years of experience in designing and manufacturing power transmission components for
railway infrastructure, power plants and other applications, known as Cariboni feeding systems.
The insulated contact line CARIBONI, series ATOLLO represents the best solution for the electrical feeding of cranes, hoists, bridge cranes, monorails, elevators, automated warehouses and several other mobile machines. It is patented and in conformance with CE standard and certificated by LOVAG.
The insulated contact line ATOLLO differs from oher feeding systems for its several advantages:
* High safety: It is in comformance with the most severe international standarts for safety requested to the lateststate-of-the-art electrical feeding system: impact protection against accidental contacts is guaranteed. Moreover the earth conductor has been marked with the relevant symbol, printed on the PVC housing;
Cariboni centre of excellence based in Lecco has 110 years of experience in designing and manufacturing power transmission components for
railway infrastructure, power plants and other applications, known as Cariboni feeding systems.
The insulated contact line CARIBONI, series ATOLLO represents the best solution for the electrical feeding of cranes, hoists, bridge cranes, monorails, elevators, automated warehouses and several other mobile machines. It is patented and in conformance with CE standard and certificated by LOVAG.
The insulated contact line ATOLLO differs from oher feeding systems for its several advantages:
* High safety: It is in comformance with the most severe international standarts for safety requested to the lateststate-of-the-art electrical feeding system: impact protection against accidental contacts is guaranteed. Moreover the earth conductor has been marked with the relevant symbol, printed on the PVC housing;
Gearbox
The new generation of CESAN gearboxes is of a monoblock (one-piece housing) design, which has the advantages of lower noise level, reduced oil leakage and higher rigidity and gear strength.
All bearings are supported by the housing itself and not by split housings. All axes are machined on the same mounting plate, which gives a high precision on all axes with very tight tolerances.
The gear manufacturing processes used allows exceptionally tight gear tolerances. This requires machining of the GG22 material housing to obtain the same tight tolerances, which can be achieved only with a monoblock housing.
The one-piece housing also makes higher bearing and gear life as well as greater overhung loads possible.
Gear strength, bearing life, shaft strength etc. are calculated with professional software applications according to DIN and Niemann’s calculation principles.
The middle bearing support plate is integrally cast and provides optimum support for bearings used in three-stage gearboxes.
The middle bearing support plate allows the gears to be supported from both sides and very close to the gear wheel.
This minimizes runout and deformation on running under load, making it possible to make low noise gearboxes.
The new generation of gearboxes feature many additional mounting possibilities.
According to customer specifications IEC B14, B5 or standard coupled geared motors are available.
All models are two- or three-stage and foot- or flange-mounted.
The new gearboxes have lower axle heights than the old models and are more compact at the same power and speed.
All gearboxes are of a modular design, allowing double gearboxes to be integrated with minimum change.
All gearbox tolerances are actively checked by our quality control system.
Hook
IIn accordance with DIN 15401-15402 norms, closed beaked hook
beaks are used with hot forging technique. Class P, T, V are used.
The hook has a spring-loaded safety cylinder. Hook has a bearing on
the base roller and has the ability to rotate 360 degrees on its axis.
Wire Rope
CESAN uses PHYTON brand of German wire ropes with
a breaking strength of 2160 N / mmІ. The rope
composition is called PHYTON COMPAC 8. With this rope
in use, a different rope geometry was developed in the
rope structure, high efficiency on operational life, high
performance and high rotation resistance.
